Chapter 5 Connecting computers and other devices
docs.smarttech.com/kb/171745 66
Input source Maximum resolution Refresh rate
Display Port 3840×2160 60 Hz
AV 1920×1080 60 Hz
YPbPr 1920×1080 60 Hz
If possible, set connected computers to these resolutions and refresh rates. See the computers’ operating
system documentation for instructions.
Using recommended cables
SMART recommends the following varieties of cable:
Cable type Maximum length Recommendation
Display Port 23' (7 m)
2
Use only certified Display Port 1.4 cables that have been
tested to support the performance standard you
require.
HDMI 23' (7 m) Use only certified Premium High-Speed HDMI (18
Gpbs) cables that have been tested to support the
performance standard you require.
VGA 23' (7 m) Use VGA cables with all pins in their connectors fully
populated and wired.
Stereo 3.5 mm 20' (6 m) Use only shielded 3.5 mm cables
Important
Use only a 3.5 mm stereo jack (15 mm long barrel) to
connect to the display.
USB 2.0 16' (5 m) Use a Hi-Speed USB 2.0 USB extender if the distance
between the computer and the display is greater than
16' (5 m).
See
USB extenders
on page12
USB 3.0 9' (3 m) SMART supports only installations that use directly
connected video and USB cables, or AC-powered
extenders.
You might be able to use higher-grade cables that
exceed the recommended length. If you have problems
with such a cable or an extender of any type, test the
connection with a shorter cable before contacting
SMART Support.
2
The performance of cables longer than 23' (7 m) is highly dependent on the cable’s quality.
