In the left navigation bar, click Device Info > WAN. The following page appears.
The fields on this page are explained in the following table.
Field Name Description
Interface The connection interface (Layer 2 interface) through which the gateway handles the traffic.
Description The service description such ipoe_0_0_1, showing the type of WAN and its ID.
Type The service type. Options are PPPoE, IPoE, and Bridge.
VlanMuxId The VLAN ID. Options are Disabled or 0-4094.
IPv6 The state of IPv6. Options are Enabled and Disabled.
Igmp Pxy The IGMP proxy.
Igmp Src Enbl The IGMP source option is enabled for this connection.
MLD Pxy The MLD proxy.
MLD Src Enbl The MLD source option is enabled for this connection.
NAT The state of NAT. Options are Enabled and Disabled.
Firewall The state of the Firewall. Options are Enabled and Disabled.
Status The status of the WAN connection. Options are Disconnected, Unconfigured, Connecting, and
Connected.
IPv4 Address The obtained IPv4 address.
IPv6 Address The obtained IPv6 address.
