SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 62
Field Name Description
Trigger Port End Enter the end number of the range of available outgoing trigger ports. Options are: 1 -
65535.
Trigger Protocol Select the protocol required by the application that will be using the ports in the specified
range. Options are: TCP, UDP, and TCP/UDP.
Open Port Start Enter the starting number of the range of available incoming ports. Options are: 1 - 65535.
Open Port End Enter the end number of the range of available incoming ports. Options are: 1 - 65535.
Open Protocol Select the protocol for the open port. Options are: TCP, UDP, and TCP/UDP.
DMZ Host
The Broadband Router will forward IP packets from the WAN that do not belong to any of the applications configured in the Virtual
Servers table to the DMZ host computer. If you want to route all internet traffic to a specific LAN device with no filtering or security,
add the IP address of that device to this page.
1. In the left navigation bar, click Advanced Setup > NAT > DMZ Host. The following page appears.
2. Enter the DMZ Host IP Address.
3. Click Apply/Save to commit your change.
Security
In this section, you can configure filtering for IP and MAC addresses.
