Field Name Description
Rate shaping).
Default Queue Shaping
Burst Rate
The maximum rate at which traffic can pass through the queue. Options are 1600 or
greater.
ETH Interface
On this page, you can configure an Ethernet interface for your gateway.
Note: If a WAN port is already configured, you must remove it before you can define a new one. The Add button does not appear
until the existing port is removed. Modify or delete any WAN service that uses it. Then, return to this page and click the Remove
checkbox and then click the Remove button.
1. In the left navigation bar, click Advanced Setup > Layer2 Interface > ETH Interface. If no WAN port is configured, the fol-
lowing page appears.
2. Click Add.
3. If a WAN port is already configured or you clicked Add, the following page appears.
4. Select the LAN port you wish to act as a WAN port.
5. Click Apply/Save to commit your changes.
