WAN Service
On this page, you can view the received and transmitted bytes, packets, errors and drops for each WAN interface for your SmartRG
Gateway. Data is provided for the total bytes, packets, errors and drops as well as bytes and packets for multicast transmissions, and
packets for unicast and broadcast transmission. All WAN interfaces configured for your gateway are included.
In the left navigation bar, click Device Info > Statistics > WAN Service. The Statistics - WAN page appears where you can view
detailed information about the status of your WAN.
To reset the counters, click Reset Statistics near the bottom of the page.
The fields on this page are explained in the following table.
Field Name Description
Interface Available WAN interfaces. Options are:
atm
,
ptm
, and
eth
.
Description Service description. Options are:
pppoe
,
ipoe
, and
bridge
.
Received
&
Transmitted
columns
Bytes Number of packets in bytes.
Pkts Number of packets.
Errs Number of error packets.
Drops Number of dropped packets.
xTM
On this page, you can view the ATM/PTM statistics for your gateway. All WAN interfaces configured for your SmartRG gateway are
included.
In the left navigation bar, click Device Info > Statistics > xTM. The Interface Statistics page appears.
To reset these counters, click Reset near the bottom of the page.
