Field Name Description

promised if one of the long-term keys in the set is compromised.

l Enable: Prevents long-term key from being compromised.

l Disable: Permits long-term keys to be compromised.

The following fields appear below

Advanced Settings

when

Manual

is selected in the

Key Exchange Method

field.

Encryption Algorithm Select the encryption algorithm. Options are DES, 3DES and AES.

Encryption Key Enter the hex value for the selected encryption algorithm.

Authentication Algorithm Select the authentication algorithm. Options are

MD5

and

SHA1

Authentication Key Enter the hex value for the selected authentication algorithm.

SPI Enter the hex value for the service provider interface (SPI). The default is

101

Advanced IKE Settings

You can configure advanced IKE settings if desired.

1. On the IPSec Settings page, click Show Advanced Settings to display the Phase 1 and Phase 2 fields.

2. Fill in the fields, using the information in the table below.

Field Name Description

Mode Select a mode. Options are Main and Aggressive.

Encryption Algorithm Select the encryption algorithm. Options are DES, 3DES , AES -128, AES-192, and

AES-256.

Integrity Algorithm Select the integrity algorithm. Options are MD5 and SHA1.

Select Diffie-Hellman Group

for Key Exchange

Select the D-H group. Options are 768bit - 8192bit. The default is 1024bit.

Key Life Time Enter the number of seconds that a key is valid. The default is 3600 seconds.

3. Click Apply/Save to commit your changes.

SMART/RG SR506n User Manual
