SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 63
IP Filtering - Outgoing
On this page, you can add an outgoing filter when refusal of data transmitted from the LAN to the WAN is desired.
1. In the left navigation bar, click Advanced Setup > Security > IP Filtering and then click Add. The following page appears.
2. Fill in the fields, using the information in the table below.
3. Click Apply/Save to commit the completed entry.
The fields on this page are explained in the following table.
Field Name Description
Filter Name Enter a descriptive name for this filter.
IP Version For the filter to be configured and effective for IPV6 , the gateway must be installed on a net-
work that is either a IPV6-only network (with that protocol enabled) or is both IPV4 and IPV6 dual
protocol enabled/configured. Options are IPv4 and IPv6. The default is IPv4.
If you select IPV6, both the Source and Destination IP address must be specified in IPV6 format.
The following is an IPV6-compliant, hexadecimal address:
2001:0DB8:AC10:FE01:0000:0000:0000:0001.
Protocol Select the protocol profile for the filter you are defining. TCP/UDP is most commonly used. The
options are TCP/UDP, TCP, UDP, and ICMP.
Source IP Enter the source IP address of a LAN side host for which you wish to filter/block outgoing traffic
