SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 142
1. In the left navigation bar, click Management > Access Control > Services. The following page appears.
2. Modify settings as needed, using the information in the following table.
3. Click Save/Apply to commit your settings.
The fields on this page are explained in the following table.
Field Name Description
Services Select the SCL services that you want to be enabled. Options are FTP, HTTP, ICMP, SNMP,
SSH, TELNET, and TFTP.
Use encrypted HTTP
(S)
Click this checkbox to implement secured HTTP.
Warning: When you click this option, the gateway reboots.
LAN Select the services enabled on LAN side firewall. Depending on configuration settings made
elsewhere in the GUI, this column may be read-only.
Note: ICMP is an always-enabled service by default and has no checkbox.
WAN Select the services enabled on the WAN side firewall.
WAN Port Number Enter the port to which the access control applies on the WAN side for the given service.
