SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 26
2. Modify the settings as desired, using the information provided in the table below.
3. Click Apply/Save to commit your changes.
The fields on this page are explained in the following table.
Field Name Description
VPI Enter a Virtual Path Identifier. A VPI is an 8-bit identifier that uniquely identifies a network path
for ATM cell packets to reach its destination. A unique VPI number is required for each ATM
path. This setting works with the VCI. Each individual DSL circuit must have a unique VPI/VCI
combination. String limits are: 0-255.
VCI Enter a Virtual Channel Identifier. A VCI is a 16-bit identifier that has a unique channel. Options
are: 32-65535.
Select DSL Select the level of DSL latency. Options are:
