Field Name Description
through NAT. Used for Voice over IP (VOIP) applications.
Enable IGMP
Multicast Proxy
Click to enable Internet Group Membership Protocol (IGMP) multicast. Used by IPv4 hosts to
report multicast group memberships to any neighboring multicast routers.
Enable IGMP
Multicast Source
Select to enable this service to act as an IGMP multicast source.
MTU sizes Enter the MTU (Maximum Transmission Unit) size for SmartRG gateways supporting a gigabit-cap-
able WAN interface. Options are 1370 - 1492 bytes. The default is 1492 bytes.
Firmware v2.5.0.7 or later is required.
Use Base MAC
Address on this
WAN interface
Use the SmartRG Devices Base (Primary) MAC address. When unchecked, a unique MAC is
assigned for each service.
Enable
MACClone
(
Appears when Use Base MAC Address is deselected
) Enter the MAC address to be used as the
close address.
