SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 44
Field Name Description
(IAPD) by MAC address.
Use the following Static
IPv6 address
Select this option to manually declare the v6 Static IP information provided by your
ISP.
WAN IPv6 Address/Prefix
Length
If entering a static IP address, enter the IP address / prefix length. If you do not spe-
cify a prefix length, the default of /64 is used.
Specify the Next-Hop IPv6
address
Enter the IP address of the next WAN in the group. This address can be either a local
link or a global unicast IPv6 address.
7. Click Next. The NAT settings page appears.
8. Click Next.
9. Modify the settings if desired. All settings are optional.
Network Address Translation (NAT) allows you to share one Wide Area Network (WAN) IP address for multiple computers on
