2. Select an ATM interface for the WAN service and then click Next. The following page appears.
3. Select Bridging. The Multicast Source fields appear.
4. Modify the other fields as needed, using the information in the following table.
Field Name Description
Allow as IGMP Multicast
Source
Select to enable this service to act as an IGMP multicast source.
Allow as MLD Multicast
Source
Select to enable this service to act as an MLD multicast source.
Enter Service Descrip-
tion
(Optional) Enter a name to describe this configuration.
Enter 802.1P Priority
Options are 0 - 7. The default is -1 (disabled).
For tagged service, enter values in this field and the 802.1Q VLAN ID field.
For untagged service, accept the default of -1 in this field and in the 802.1Q VLAN ID
field.
Enter 802.1Q VLAN ID
Options are 0 - 4094. The default is -1 (disabled).
