SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 54
Field Name Description
Automatically create
static IP leases from
the following OUIs
For LAN hosts, IP addresses can be assigned manually or by using DHCP. Click Add OUI.
Enter the OUI and click Apply/Save. Repeat these steps to create any additional entries
that you need.
Configure DHCP Options
section
Option 66 For devices that require access to a TFTP server (device configuration name files are in .cnf
file format), which enables the device to communicate with other infrastructure, select
this option to specify the name of the TFTP server.
Option 150 A Cisco proprietary methodology for pointing to one or two TFTP servers.
Configure the second
IP address and sub-
net mask for LAN
interface
When you select this option, the IP Address and Subnet Mask fields appear where you can
enter a second IP address and Subnet mask to support a second, simultaneous LAN, i.e., the
primary LAN might be defined as 192.168.0.1 and this secondary LAN defined as 192.168.2.1.
