SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 76
Field Name Description
default is Enable.
Specify Classification Criteria section
Ingress Interface Select an interface for incoming data. Options are
LAN
,
WAN
,
Local
and any interface
already configured for your gateway.
Ether Type Select the Ethernet interface type for this classification. Options are IP, ARP, IPV6,
PPPoE_DISC, pPPoE_SES, 8865, 8866, and 8021Q.
802.1P priority (For Ether Type of 8021Q only) This value is inserted into the Ethernet frame and
used to differentiate traffic. Lower values assign higher priorities. Options are: 1 - 7.
Source MAC Address
Source MAC Mask
(Not applicable for Ether Type of 8021Q) Enter the source MAC Address and Source
MAC Mask for this classification.
Destination MAC Address
Destination MAC Mask
(Not applicable for Ether Type of 8021Q) Enter the destination MAC Address and des-
tination MAC Mask for this classification.
Source IP Address[Mask] (Not applicable for Ether Type of 8021Q) (Optional) Enter the source IP address and
subnet mask for this classification, or select a DHCP option from the drop-down list and
enter the address and mask for that server.
Destination IP Address
[Mask]
(Optional) (Not applicable for Ether Type of 8021Q) Enter the destination IP address
and subnet mask for this classification.
Differentiated Service
Code Point (DSCP) Check
(Optional) (Not applicable for Ether Type of 8021Q) Select the desired DSCP code for
marking incoming data.
Protocol (Optional) (Not applicable for Ether Type of 8021Q) Enter the Protocol specified for
this classification.
Specify Class Queue (Not applicable for Ether Type of 8021Q) Select from the available queues.
Note: Make sure to select a queue that is configured for the interface that you selec-
ted. If you select a queue that is not configured for the selected interface, any packets
classified into that queue are processed by the default queue for the interface.
Specify Classification Results
section
Specify Egress Interface Select the egress interface for this rule. Options are the interfaces already configured.
Specify Egress Queue Select the egress queue for this rule. Options are the queues already configured.
Mark Applied Dif-
ferentiated Service Code
Point
Select the desired DSCP code for marking classification results.
