・ General diagnostics 2
Table. 5-3 General diagnostics 2
Bit
Description
Explanation
0 Module 1 error 0: No error or not connected, 1: Module 1 has an error
1
Module 2 error
0: No error or not connected, 1: Module 2 has an error
2
Module 3 error
0: No error or not connected, 1: Module 3 has an error
3
Module 4 error
0: No error or not connected, 1: Module 4 has an error
4
Module 5 error
0: No error or not connected, 1: Module 5 has an error
5
Module 6 error
0: No error or not connected, 1: Module 6 has an error
6
Module 7 error
0: No error or not connected, 1: Module 7 has an error
7 Module 8 error 0: No error or not connected, 1: Module 8 has an error
・ Valve diagnostics 1
Table. 5-4 Valve diagnostics 1
Bit
Description
Explanation
0 Valve 0, 1 diagnostics 0: No error, 1: Short circuit
1
Valve 2, 3 diagnostics
0: No error, 1: Short circuit
2
Valve 4, 5 diagnostics
0: No error, 1: Short circuit
3
Valve 6, 7 diagnostics
0: No error, 1: Short circuit
4
Valve 8, 9 diagnostics
0: No error, 1: Short circuit
5
Valve 10, 11 diagnostics
0: No error, 1: Short circuit
6
Valve 12, 13 diagnostics
0: No error, 1: Short circuit
7
Valve 14, 15 diagnostics
0: No error, 1: Short circuit
・ Valve diagnostics 2
Table. 5-5 Valve diagnostics 2
Bit
Description
Explanation
0 Valve 16, 17 diagnostics 0: No error, 1: Short circuit
1
Valve 18, 19 diagnostics
0: No error, 1: Short circuit
2
Valve 20, 21 diagnostics
0: No error, 1: Short circuit
3
Valve 22, 23 diagnostics
0: No error, 1: Short circuit
4
Valve 24, 25 diagnostics
0: No error, 1: Short circuit
5
Valve 26, 27 diagnostics
0: No error, 1: Short circuit
6
Valve 28, 29 diagnostics
0: No error, 1: Short circuit
7
Valve 30, 31 diagnostics
0: No error, 1: Short circuit
