SMC Networks EX245-EA2 Series User Manual

- 32 -
No.EX※※-OMW0011-B
5.1.2. Diagnostics type 2
Table. 5-6 Overview of Diagnostics type 2
Byte
Description
0
General diagnostics 1
1 Valve diagnostics 1
2
General diagnostics 2
3
Valve diagnostics 2
・ General diagnostics 1
Table. 5-7 General Diagnostics 1
Bit
Description
Explanation
0 Maximum number of valves
0: 16 Valves
1: 32 Valves or no "Valves" module
1 Valve coil(s) short circuit
0: No valve coil(s) have a short circuit
1: At least one valve coil has a short circuit
2 US1 diagnostics 1
0: US1 present
1: US1 has dropped (< approx. 19.2 VDC)
3 Reserved Fixed 0
…
…
…
7
Reserved
Fixed 0
・ Valve diagnostics 1
Table. 5-8 Valve diagnostics 1
Bit
Description
Explanation
0
Valve 0, 1 diagnostics
0: Short circuit, 1: No error
1
Valve 2, 3 diagnostics
0: Short circuit, 1: No error
2
Valve 4, 5 diagnostics
0: Short circuit, 1: No error
3
Valve 6, 7 diagnostics
0: Short circuit, 1: No error
4
Valve 8, 9 diagnostics
0: Short circuit, 1: No error
5 Valve 10, 11 diagnostics 0: Short circuit, 1: No error
6
Valve 12, 13 diagnostics
0: Short circuit, 1: No error
7
Valve 14, 15 diagnostics
0: Short circuit, 1: No error
