Interface Commands
4-119
4
• If autonegotiation is disabled, auto-MDI/MDI-X pin signal configuration will
also be disabled for the RJ-45 ports.
Example
The following example configures port 11 to use autonegotiation.
Related Commands
capabilities (4-119)
speed-duplex (4-117)
capabilities
This command advertises the port capabilities of a given interface during
autonegotiation. Use the no form with parameters to remove an advertised
capability, or the no form without parameters to restore the default values.
Syntax
[no] capabilities {1000full | 100full | 100half | 10full | 10half | flowcontrol |
symmetric}
• 1000full - Supports 1000 Mbps full-duplex operation
• 100full - Supports 100 Mbps full-duplex operation
• 100half - Supports 100 Mbps half-duplex operation
• 10full - Supports 10 Mbps full-duplex operation
• 10half - Supports 10 Mbps half-duplex operation
• flowcontrol - Supports flow control
• symmetric (Gigabit only) - When specified, the port transmits and receives
pause frames; when not specified, the port will auto-negotiate to determine
the sender and receiver for asymmetric pause frames. (The current switch
ASIC only supports symmetric pause frames.)
Default Setting
• 100BASE-TX: 10half, 10full, 100half, 100full
• 1000BASE-T: 10half, 10full, 100half, 100full, 1000full
• SFP: 1000full
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
When auto-negotiation is enabled with the negotiation command, the switch
will negotiate the best settings for a link based on the capabilites command.
When auto-negotiation is disabled, you must manually specify the link
attributes with the speed-duplex and flowcontrol commands.
Console(config)#interface ethernet 1/11
Console(config-if)#negotiation
Console(config-if)#
