Command Line Interface
4-184
4
Command Mode
Privileged Exec
Example
This shows that traffic entering Port 1 that matches the specifications for protocol
group 1 will be mapped to VLAN 2:
Priority Commands
The commands described in this section allow you to specify which data packets
have greater precedence when traffic is buffered in the switch due to congestion.
This switch supports CoS with four priority queues for each port. Data packets in a
port’s high-priority queue will be transmitted before those in the lower-priority
queues. You can set the default priority for each interface, the relative weight of each
queue, and the mapping of frame priority tags to the switch’s priority queues.
Priority Commands (Layer 2)
Console#show interfaces protocol-vlan protocol-group
Port ProtocolGroup ID Vlan ID
---------- ------------------ -----------
Eth 1/1 1 vlan2
Console#
Table 4-61 Priority Commands
Command Groups Function Page
Priority (Layer 2) Configures default priority for untagged frames, sets queue weights,
and maps class of service tags to hardware queues
4-184
Priority (Layer 3 and 4) Maps IP DSCP tags to class of service values 4-189
Table 4-62 Priority Commands (Layer 2)
Command Function Mode Page
queue mode Sets the queue mode to strict priority or Weighted
Round-Robin (WRR)
GC 4-185
switchport priority default Sets a port priority for incoming untagged frames IC 4-185
queue bandwidth Assigns round-robin weights to the priority queues GC 4-186
queue cos map Assigns class-of-service values to the priority queues IC 4-187
show queue mode Shows the current queue mode PE 4-188
show queue bandwidth Shows round-robin weights assigned to the priority queues PE 4-188
show queue cos-map Shows the class-of-service map PE 4-189
show interfaces switchport Displays the administrative and operational status of an
interface
PE 4-125
