Link Aggregation Commands
4-139
4
Table 4-49 show lacp neighbors - display description
Field Description
Partner Admin System ID LAG partner’s system ID assigned by the user.
Partner Oper System ID LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port Number
Current administrative value of the port number for the protocol Partner.
Partner Oper
Port Number
Operational port number assigned to this aggregation port by the port’s protocol
partner.
Port Admin Priority Current administrative value of the port priority for the protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the partner.
Admin Key Current administrative value of the Key for the protocol partner.
Oper Key Current operational value of the Key for the protocol partner.
Admin State Administrative values of the partner’s state parameters. (See preceding table.)
Oper State Operational values of the partner’s state parameters. (See preceding table.)
Console#show lacp sysid
Port Channel System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-12-CF-8F-2C-A7
2 32768 00-12-CF-8F-2C-A7
3 32768 00-12-CF-8F-2C-A7
4 32768 00-12-CF-8F-2C-A7
Console#
Table 4-50 show lacp sysid - display description
Field Description
Channel group A link aggregation group configured on this switch.
System Priority
*
LACP system priority for this channel group.
System MAC Address
*
System MAC address.
* The LACP system priority and system MAC address are concatenated to form the LAG system ID.
