Scope Multimeter General Reference
(kPa) KiloPasca 1 kPa = 1000 Pa
(MPa) Megapascal 1 MPa = 1,000,000 Pa
(inHg) inches of mercury
1 inHg = 0.03386388 bar
1 inHg = 0.4911541 psi
1 inHg = 3386.388 Pa
Pressure Conversions
psi x 0.0689 = bar
psi x 6.8950 = kPa
psi x 0.0703 = kg/cm²
bar x 14.5030 = psi
bar x 100.0000 = kPa
bar x 29.5300 = inHg (60°F)
kPa x 0.1450 = psi
kPa x 0.0100 = bar
kPa x 0.0102 = kg/cm²
kPa x 0.295299 = inHg
kg/cm² x 98.0700 = psi
kg/cm² x 0.9807 = bar
kg/cm² x 14.2200 = kPa
inHg (60°) x 0.0333 = bar
inHg (60°) x 3.3770 = kPa
inHg (60°) x 0.0344 = kg/cm²
inHg x 25.4 = mmHg
mmHg x 0.003994 = inHg
Temperature Units
(Symbol) / Description Conversions
(°C) degree Celsius °C = 0.556 x (°F - 32)
(°F) degree Fahrenheit °F = (1.8 x °C) + 32
Time Units
(Symbol) / Description Equivalents
(µs) microsecond 1 µs = 0.000001 of a second
(ms) millisecond 1 ms = 0.001 of a second
(s) second 1 s = 1000 ms
Duty % to Dwell Conversions
Duty Cycle Dwell
% 4 cyl 6 cyl 8 cyl
10 9.0 6.0 4.5
20 18.0 12.0 9.0
30 27.0 18.0 13.5
Pressure Units
(Symbol) / Description Equivalents
