Chapter 2 Introduction
The MODIS Ultra is a multi-function tool that combines a scan tool with a two-channel lab scope,
graphing multimeter, and the exclusive Snap-on Guided Component Test database into a single
hand-held unit.
This chapter describes the construction of the diagnostic tool and addresses the use of the basic
hardware controls and features in the following sections:
• Functional Description
• Technical Specifications‚ on page 7
• Control Keys‚ on page 8
• Power Sources‚ on page 9
• The Stand‚ on page 10
2.1 Functional Description
1— N/X key (No, Cancel, or Return)
2— Y/a key (Yes, Accept, or Continue)
3— Directional key; left (e), right (c), up (b), down (d)
4— Shortcut key
5— Power key
Figure 2-1 Front view






Snap-On Modis Ultra Specifications

General

Display Size	8 in
Operating System	Android
Storage	32 GB
Connectivity	Wi-Fi, Bluetooth
Warranty	1 year
Battery	Lithium-ion
Scanner	Integrated
Battery Life	10 hours
Display Type	Touchscreen LCD
Power	AC/DC adapter
