Snap-On Solus User Manual

5
Introduction Functional Description
1— Liquid Crystal Display (LCD)
2— N/X (No) and Y/a (Yes) buttons
3— Thumb Pad
4— Right handgrip
5— Brightness/Contrast button
6— S button
7— Power button
8— Left handgrip
Figure 2-2
Front view
1— DC power supply input
2— USB port
3— Infrared (IR) output
4— CompactFlash
®
(CF) Card Slot 1
5— CF Card Slot 2
6— Data cable connector
Figure 2-3
Top view
1
2
3
87
65
4
12345 6
