46
Operations Viewing Saved Data
NOTE:
i Frame files are saved with a SC(S) file type designation.
z To save an image file:
1. Select the Save button from the toolbar.
A drop-down menu displays (Figure 5-40).
2. Select Save Image from the drop-down menu.
The Saving screen image... message displays.
NOTE:
i The S button can be set to save an image file, see “S Button” on page 59 for details.
z To review an image file:
1. Select the Saved Data button from the main menu.
2. Select the Data Management option (Figure 5-42).
3. A list of all saved files displays.
4. Select the file that you would like to review.
NOTE:
i Image files are saved with either a BMP or JPG file type designation.
5.10 Viewing Saved Data
Use the Saved Data button to access the Data Management screen option.
The Data Management screen lets you manage your scan tool memory and your saved files
(Figure 5-44).
Figure 5-44
Sample Data Management screen
1— Saved data files
The saved files available depend on the CF Slot destination selected in the Setup menu.
2— Load button
Opens the saved file selected.
1
234 5 6 7 8 9 10
11
