59
Operations Utilities
SButton
Selecting S Button allows you to change the functionality of the S button. Possible function
assignments include:
• Save Image—is the default and takes a snapshot of the current screen. The snapshot is
saved as either a bitmap or a jpeg image, which can be opened using standard Internet
browsers or graphics applications. This feature works anywhere in scan tool operations.
• Freeze/Run—works as the Pause/Play button when viewing data in the Graphs or PID List
views. See “Pausing Data” on page 41 for details.
• Save Frame—works as the Save Frame selection from the Save button in the upper toolbar
when this option is available. See “Saving Captured Data” on page 44 for details.
• Print List—works like the Full PID List selection from the Print button in the upper toolbar.
See “Printing” on page 51 for details.
• Print Page—works like the Full Screen selection from the Print button in the upper toolbar.
See “Printing” on page 51 for details.
• S Button Popup—opens the menu when the button is pressed so you can quickly select from
any of the available functions.
NOTE:
i The S button can only perform print functions when the Print button is visible in the upper toolbar.
z To assign a function to the S button:
1. Select Utilities > Tool Setup > S Button.
The S Button dialog box displays.
2. Press Y/a to open the drop-down list (Figure 5-64).
Figure 5-64
Sample S Button dialog box
3. Select a function from the drop-down list.
4. Press N/X to close the dialog box.
Color Theme
Color Theme lets you select a black or white background for the screen. Using the black
background helps conserve battery power
z To select a Color Theme:
1. Select Utilities > Tool Setup > Color Theme.
The Color Theme dialog box displays.
2. Press Y/a to open the drop-down list (Figure 5-65).
To Next Page
