Introduction Cables
• “Installing the Batteries” on page 14
• “Power Management” on page 55
• “Replacing the Batteries” on page 64
2.6.3 AC/DC Power Supply
This scan tool can be powered from a wall socket using the optional AC/DC power supply
(Figure 2-7).
Figure 2-7
AC/DC power supply
For related information, see the following sections:
• “DC Power Input” on page 9
• “Connecting an AC/DC Power Supply” on page 16
2.7 Cables
This scan tool uses the following cables:
• Data cable
• Power cables (cigarette lighter and battery)
2.7.1 Data Cable
The data cable (Figure 2-8) is included with your scan tool and uses interchangeable test adapters
for connecting to vehicle diagnostic connectors.Captive screws secure both data cable ends.
Figure 2-8
Data Cable
