7.3. UPS DATA BASE
NET VISION manages 2 types of UPS mapping:
• ‘JBUSP’ mapping for NETYS PR - RT / ITYS / MODULYS / MASTERYS MC-BC-GP-IP-EM /
DELPHYS BC-GP-Xtend
• ‘VU-MAP’ mapping for ITYS-PRO / MODULYS GP 2.0 / MASTERYS BC+ and GP4 ranges and
future SOCOMEC UPS range.
JBUSP TABLES
STATUS S00 – S63 0x1020 4 w
ALARMS A00 – A63 0x1040 4 w
MEASUREMENTS M00 – M47 0x1060 48 w
VU-MAP TABLES
STATUS S000 – S127 0x0030 8 w
ALARMS A000 – A127 0x0038 8 w
MEASUREMENTS M000 – M079 0x0040 80 w
MODBUS TCP access must follow the addresses according to the UPS mapping
Please refer to the Appendix: MODBUS TCP JBUSP and VU-MAP TABLE.
7.4. UPS ARCHITECTURE:
• Single Unit 1 phase and 3 phases
• Converter - without battery
• Module – without bypass
• Modular Unit up to 8 modules
• Parallel system, distributed bypass or centralized bypass, up to 6 Units (JBUSP) and 10 Units
(VU-MAP)
• Modular system up to 3 Units – 24 modules.
