NET-VISION 7 - SOCOMEC
appendix: teChniCal information
LED Denition
The function of the NET VISION is indicated by the Status/EMD and Network LEDs, as listed in
the following table.
Port Green LED Yellow LED Function
Network
ON Flashing(1sec) Ethernet 100 Trafc
OFF Flashing(1sec) Ethernet 10 Trafc
ON ON 100 Base-TX Ready
OFF ON 10 Base-T Ready
OFF OFF Ethernet Disconnection
Status/
EMD
OFF Flashing ~1 second UPS detection
ON OFF UPS detected, no com with UPS
ON Flashing Communication with UPS
Two LEDs cross Flashing Two LEDs cross Flashing Auto Diagnostic Mode
ON ON Auto Diagnostic Failed
OFF OFF Hardware Error
Technical specication
Function Description
Power Input NV with USB (Host) function voltage: +7.5V ~ 40V
Power Consumption 3.0 Watts Maximum
SMT Switch SMT switch on the board for conguration
Dimensions (L x W x H mm) 129.9(L) x 60.0(W) mm
Operating Temperature -20 ~ 70° C
Operating Humidity 10 ~ 80 % (Non-condensing)
