NET-VISION 7 - SOCOMEC
19.3. NET VISION CONTROL
Conguration Default value Description
“BootP/DHCP”
“PING Echo”
The ping answer can be disabled
“Network Upgrade”
The FW upgrade, through TFTP, from NET VISION Explorer
can be disabled.
“Force Security HTTP” Port 443
To enable HTTPs secure connection
“HTTP Port” Port 80
To enable web page and changing port
“HTTP Security Control”
To force login request when web page is open
“SSH Connection” Port 22
To enable remote console (such as putty tool ) for NET VI-
SION conguration
“SNMP Support” Port 161
To enable connection to NMS
“SMTP Support” Port 25
To enable email functions
“UPnP Control”
To enable NET VISION as a Network device
“RADIUS/Authentication”
To enable authentication protocol page settings
“WOL Target”
To enable Wake On LAN settings page.
Protocol to restart servers when NET VISION restarts after a
shutdown due to AC failure.
“Modbus Conguration”
To enable MODBUS TCP protocol
“Syslog Setup”
To enable Syslog settings page
“DDNS Setup”
To enable DDNS settings page
“Firewall Setup”
To enable Firewall settings page
“SNMP Unit Select”
0 for System
Unit 1 to 12
0 to populate all SNMP OID with UPS data at system level.
Set to unit number to populate all SNMP OID with the local
UNIT data where the NET VISION is connected.
NET VISION must be installed on each Unit.
“SNMP TRAP / E-mail Filter” Disabled
This function enable or disable TRAP3 and TRAP4 notica-
tion when “severity” level is set as lter to send TRAP or
e-mail.
