Notifications on the LCD Status Display (Solar-Log 300, 1200 and 2000)
8 Notifications on the LCD Status Display
(Solar-Log 300, 1200 and 2000)
The Solar-Log 300, 1200 and 2000 have an LCD status display for notifications during installation and
operation.
8.1 Meaning of the symbols on the LCD display
The following symbols are shown on the Solar-Log™ LCD display:
Fig.: LCD Status Display with all of the symbols
Meaning of the symbols on the LCD display
Symbol Meaning
Inverters
Internet or Network
Firmware update progress
