Solar-Log 1000 User Manual

43
Operating via a web browser within your own network
2.11 Accessing Diagnostic values
Access the Diagnostic from the header bar.
The following options can be selected from the
left-side navigation menu.
•
Inverter Diagnostic
•
Event log
•
Notifications
•
Feed-In Management
•
SCB Monitor (only Solar-Log 2000 with SCB activated)
•
Alarm contact (only Solar-Log 2000)
•
CSV Export
2.11.1 Inverter Diagnostic
To access the Inverter diagnostic menu, go to Diagnostic | Inverter Diagnostic.
The following tabs can be selected from this menu:
•
Inverter details
•
Tracker comparison
•
Module field comparison
Different values with different units are displayed in the following diagnostic graph. A key is displayed for
every graphic to define which units are used and their colors.

Solar-Log 1000 Specifications

General

Max Inverters	100
Display	LCD
Power Supply	24 VDC
Data Storage	SD Card
Enclosure Protection	IP20
Maximum Number of Strings	100
Ethernet Ports	1
USB Ports	1
Communication Interfaces	Ethernet, RS485
Supported Communication Protocols	Modbus, SunSpec
Power Consumption	5 W
