Technical Data (Solar-Log 300, 1200 and 2000)
10 Technical Data (Solar-Log 300, 1200 and
2000)
Product comparison Solar-Log 300 Solar-Log 1200 Solar-Log
2000
Basic functions
PM+
(2)
PM+ / WiFi
(2)
-
PM+ / GPRS
(2)
(4)
Bluetooth (BT)
(2)
-
WiFi (Wireless LAN)
(2)
-
Bluetooth (BT) / WiFi
(2)
-
GPRS
(2)
Solar-Log
TM
Meter (CT)
-
Central inverter SCB and SMB
- -
Communication interface
1 x RS485 / RS422
(one INV manu-
facturer per bus)
1 x RS485
1 x RS485 / RS422
(one INV manu-
facturer per bus)
1 x RS485, 2x
RS485 / RS422,
1 x CAN
(one INV manu-
facturer per bus)
Max. plant size
15 kWp /
one INV man-
ufacturer
100 kWp / max.
two INV man-
ufacturers
2000 kWp /
max. three INV
manufacturers
Max. cable length max. 1000 m
1)
max. 1000 m
1)
max. 1000 m
1)
Plant monitoring
String monitoring (depend-
ing on inverter type)
Inverter failure, status of fault
and power monitoring
Sensor system connection
(irradiation/ temp./ wind)
3) 3) 3)
E-mail and Text Mes-
sage (SMS) Alarm
Alarm (local)
- -
Yield forecast and deg-
radation calculation
Self-produced energy consump-
tion: Digital electricity meter
Self-produced energy consump-
tion:
Managing external appliances

Solar-Log 1000 Specifications

General

Max Inverters	100
Display	LCD
Power Supply	24 VDC
Data Storage	SD Card
Enclosure Protection	IP20
Maximum Number of Strings	100
Ethernet Ports	1
USB Ports	1
Communication Interfaces	Ethernet, RS485
Supported Communication Protocols	Modbus, SunSpec
Power Consumption	5 W
