Solar-Log 1000 User Manual

16
Operating via a web browser within your own network
•
The current day value as well as those from the previous 5 days (graph on the right). Move the
mouse above one of the bars to display the day value. Click on one of the bars to have it display in
the graph on the left as a curve.
Additional tabs can be selected in this view:
•
Energy flow
•
Table
Note
If the Solar-Log™ is just used as a consumption monitoring tool, the menu is limited
to
Current values, Consumption and System information.
All of the other menus are hidden.
Note
When only consumption meters are connected to the Solar-Log™, a large con-
sumption tachometer is displayed instead of the production tachometer in the
Current values | Cockpit menu.

Solar-Log 1000 Specifications

General

Max Inverters	100
Display	LCD
Power Supply	24 VDC
Data Storage	SD Card
Enclosure Protection	IP20
Maximum Number of Strings	100
Ethernet Ports	1
USB Ports	1
Communication Interfaces	Ethernet, RS485
Supported Communication Protocols	Modbus, SunSpec
Power Consumption	5 W
