31
Operating via a web browser within your own network
Month View:
The
Consumption Overview and the Sub-consumer Overview.
The total consumption values are displayed in the Consumption Overview as a bar graph.
In the
Sub-consumer Overview, you see the devices connected as a bar graph with the power con-
sumption displayed in different colors. Below this, the values are also displayed in a pie chart with the
colors in the key.
There is the option from both views to select the individual months directly from the individual bars
and sections.
•
Total:
displays the Total Graph View as a bar graph. There are two tabs in the Total View, the same as in the
Year View:
The
Consumption Overview and the Sub-consumer Overview.
The total consumption values are displayed in the Consumption Overview as a bar graph.
In the
Sub-consumer Overview, you see the devices connected as a bar graph with the power con-
sumption displayed in different colors. Below this, the values are also displayed in a pie chart with the
colors in the key.
There is the option from both views to select the individual years directly from the individual bars and
sections.
