Solid State Logic C100 HDS User Manual

439+398
'-+// ? +)9/43  389'11'9/43'3:'1
##B<=/686987/7=< 
C100 HDS Console 2-13
Frame Layout 2-13
Connector Panels 2-13
Console Connectors 2-15
The Blackrock Processor 2-17
Audio Processor (DSP) 2-17
Single Board Computer (SBC) 2-17
Console Networks 2-17
Fibre I/O Ports 2-17
Blacklight links for RIO Stageboxes 2-17
Blackrock Connectors 2-19
Alpha-Link Live-R 2-21
Fibre Connection 2-21
Connector Summary 2-21
Alpha-Link Live 2-21
Alpha-Link 8-RMP 2-23
Connector Summary 2-23
Remote I/O Rack (RIO) 2-25
I/O Daughter Cards 2-25
Fibre Connection 2-25
RIO – Micamp Card 2-27
RIO – Analogue I/O Card 2-27
RIO – Digital I/O Card 2-27
Remote GP IO Interface 2-29
Chassis Grounding 2-29
Input Switching 2-29
Output Switching 2-29
MORSE System (option) 2-31
SDI–MADI Interface 2-33
Fibre Connections 2-33
#B<=/69=387< 
Script Tray 2-34
Loudspeaker Shelf 2-34
Side Arm Trim 2-34
TFT External Input 2-34
LCD Phasescope 2-34
#$ $$#C

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
