Solid State Logic C100 HDS User Manual

Supported Sync Rates
Page 4-16 | Section 4 – Appendices C100 HDS Installation Manual
%#% "$ "$#
PAL 23.976
720p 30Hz
720p 29.97Hz
720p 25Hz
720p 24Hz
720p 23.976Hz
#% "$ #) "$#
#=998:<.-#?7,"*<.;
No. Video Format Field Rate (Hz) Frame Rate (Hz) Notes
1 PAL 50 25 SD sync rates are suitable
2 PAL 24 48 24 for all units
3 NTSC 59.94 29.97
4 1080i 60Hz 60 30 HD sync rates are only
5 1080i 59.94Hz 59.94 29.97 accepted by the
6 1080i 50Hz 50 25 Blackrock processors
7 1080p 60Hz 60 60
8 1080p 59.94Hz 59.94 59.94
9 1080p 50Hz 50 50
10 1080p 30Hz 30 30
11 1080p 29.97Hz 29.97 29.97
12 1080p 25Hz 25 25
13 1080p 24Hz 24 24
14 1080p 23.976Hz 23.967 23.967
15 1080PsF 24Hz(1080i 48Hz) 24 24
16 1080PsF 23.976Hz(1080i 47.95Hz) 23.967 23.967
17 720p 60Hz 60 60
18 720p 59.94Hz 59.94 59.94
19 720p 50Hz 50 50

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
