Solid State Logic C100 HDS User Manual

>89+242543+398
'-+ ? +)9/437+5'7'9/43  389'11'9/43'3:'1
STATUS POWER
POWER INPUT TYPE GAIN
010182837455565
1 234567 8
dB
OVL
-15dB
+48v
POWER INPUT OUTPUT SAMPLE
RATE
CLOCK METERS
12345678
910111213141516
17 18 19 20 21 22 23 24
AD
DA
XS
AES
INT
EXT
44.1k
48k
96k
38.2k
AES
ANA
MADI
EXP
POWER INPUT OUTPUT SAMPLE
RATE
CLOCK METERS
12345678
910111213141516
17 18 19 20 21 22 23 24
AD
DA
XS
AES
INT
EXT
44.1k
48k
96k
38.2k
AES
ANA
MADI
EXP
C100 HDS Console
Alpha-Link Live-R
Blackrock Processor(s)
Alpha-Link 8-RMP
Router and/or
Automation
System
Sync
SSL Network
SSL Network
TCP/IP Network
Sync Source and
Distribution Amplifier
RS422 1 & 2
Phasescope audio
VU meters
TB Mic
#)#$ '" &"&'
For the majority of installations cabling will need to be installed between units as indicated below:
MORSE Stagebox
MORSE Router
GP I/O
Audio Fibre
MADI Audio – Duplex optical fibre
SSL Network – Ethernet
TCP/IP Network – Ethernet
Sync Distribution – 75R Coax
Analogue Audio – Balanced
Digital Audio – 110R Balanced
Router / Control – RS422 Serial

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
