Solid State Logic C100 HDS User Manual

Page 4-4 | Section 4 – Appendices C100 HDS Installation Manual
Specifications
591*2742>.2>."
Parameter Condition Value Unit Notes
Height 2 U
89 mm
Width 19 in
Case only without rack ears 449 mm
Depth 300 mm Excludes connectors/cables
Weight (†) 6.0 kg
Heat Dissipation 50 W Shared between two PSUs
Voltage Range 100 – 240 V ±10%, 50/60Hz AC only
Current Maximum over voltage range 0.6 – 0.3 A Maximum
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Connectors Power in 1 and 2 IEC male
Analogue Inputs 25-way D-type female
Analogue Outputs 25-way D-type female
Digital input/output 25-way D-type female
Video In (Sync) BNC 75Ω
Word Clock Out BNC 75Ω
MADI input/output Duplex SC fibre socket
Remote mic control RJ45 socket
591*274"
Parameter Condition Value Unit Notes
Height 2 U
89 mm
Width 19 in
Case only without rack ears 449 mm
Depth 300 mm Excludes connectors/cables
Weight (†) 6.0 kg
Heat Dissipation 50 W Shared between two PSUs
Voltage Range 100 – 240 V ±10%, 50/60Hz AC only
Current Maximum over voltage range 0.6 – 0.3 A Maximum
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Connectors Power in 1 and 2 IEC male
Microphone Inputs XLR 3-pin female
Line level Output 25-way D-type female
Remote control RJ45 socket
† Alpha-Link units must be supported on rack shelves. Do not rely on the rack ears alone.

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
