Solid State Logic C100 HDS User Manual

  "
The RMP provides 8 microphone amplifiers in a 2U high 300mm deep 19” rack unit. It features dual power supplies for
on-air reliability. Switchable phantom power is available on each input.
The 8-RMPs connect directly to an Alpha-Link Live unit, not to the Blackrock processor. Up to three units can be
controlled by each Alpha-Link Live.
Outputs from the 8-RMP are at line level and should be connected to the Alpha-Link Live using 8-circuit balanced audio
cable.
Remote control information is provided by a separate RJ45 data cable.* Pairs of audio-plus-control cables can be ordered
from SSL in lengths of 1m, 5m, 10m and 25m. Cable pinouts are listed in the appendices. The maximum recommended
cable length between each Alpha-link 8-RMP and an Alpha-Link Live is 50m.
$" #%")
*Standard Ethernet cables can be used to connect to Alpha-Link LIVE-R. Custom pinout is required to connect to Alpha-Link Live.
See Section 4-12 for the connector pinouts.
'2+ 433+)947 +8)7/59/43
Mic/Line In XLR3 F Microphone input. Pin 2 +ve. Switchable phantom power.
Line Out D25 F 8 channel balanced audio outputs, line level.
Remote RJ45 Control data connection to Alpha-Link LIVE-R.*
i
>89+242543+398
 389'11'9/43'3:'1 +)9/437+5'7'9/43? '-+

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
