Each C100 HDS control surface consists of a single 8-fader master section (usually referred to as the centre section) plus
additional eight-fader channel bays. Integrated racking sections, producer’s tables or corner sections are not available.
• The control surface is available in sizes of 16 to 64 channel faders – plus the centre section.
• The sides of the console are flat to reduce the overall width and to simplify the positioning of adjoining furniture.
Where consoles will be freestanding contoured side arms are available to provide a more comfortable finish.
• The console surface is connected to its Blackrock processing rack using standard Ethernet cables. These cables supply
all data required for control, channel metering and touchscreen display information. 100m is the maximum distance
permitted between the console and its computer rack. (Additional functions such as talkback or the optional loudness
metering will require additional cabling.)
Frames can be constructed to include a mechanical split point between any 8-channel section. The console can then be
separated at this point into smaller sections to simplify installation into a client’s premises. Consoles split for shipment will
require additional commissioning time.
Page 4-5 shows the dimensioned layout of a 32-channel frame. SSL’s Project Engineering Department can provide
dimensioned CAD drawings for other frame configurations – e-mail: projeng@solidstatelogic.com
Systems Integrators will be able to download CAD files of C100HDS console drawings from the SSL SI website.
" "##"
All audio and control processing functions for the C100 HDS system are provided by a separate rack-mounted
computer/DSP processor termed Blackrock.
• Blackrock is 2U high 430mm deep Refer to page 4-3 for full specifications.
• The chassis contains cooling fans with the airflow from front to back
• All connections are made to the rear of the rack
"%$ "##
Systems specified with optional processor redundancy are supplied with a second Blackrock chassis unit so an additional
2U of rack space will be required.
%$#
Separate 19” rack units are used to provide input and output connections. The type and quantity of I/O racks supplied
varies according to each user’s specific requirement for analogue, digital and microphone signals. Units available are as
follows:
• (Remote Input Output) – 7U rack; five slots for various plug-in I/O cards; contains cooling fans Page 2-25.
• 15.'/30 (LIVE-R and 8-RMP) – 2U high 300mm deep; fan-less. It is recommended that a 1U ventilation space be
added after every two Alpha-Link units when allocating rack space. Page 2-21.
• – MORSE Stageboxes are 3U and feature 14 slots into which a range of I/O modules may be fitted. Systems
that require resource sharing may also be equipped with the 6U or 3U MORSE router rack Page 2-25.
• @ – 1U chassis. De-embeds the audio data from up to four SDI audio signals (SD, HD and 3G).
• +249+ – This feature allows the console to send mic amp control over MADI to third-party amplifiers or
routing systems which use the DHD control protocol data, such as Optocore and RocNet systems.
!+).3/)'1+6:/7+2+398
389'11'9/43'3:'1 +)9/437+5'7'9/43? '-+
