C100 HDS Installation Manual Section 4 – Appendices | Page 4-3
Specifications
5*,4:8,4 :8,.;;8:
Parameter Condition Value Unit Notes
Height 2 U
89 mm
Width 19 in
Case only without rack ears 449 mm
Depth 429 mm Excludes connectors/cables
Weight (†) 14 kg
Heat Dissipation 200 W Shared between two PSUs
Voltage Range 100 240 V ±10%, 50/60Hz AC only
Current Maximum over voltage range 2.1 0.9 A Maximum
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Noise Front 50 NR Both PSUs powered
Rear 55 NR Both PSUs powered
Connectors Power in 1 and 2 IEC male
Networks RJ45
Sync In BNC 75Ω
Fibre I/O Duplex LC Multimode or singlemode to order
Blackrock processor units must be supported on rack shelves. Do not rely on the rack ears alone.
"
Parameter Condition Value Unit Notes
Height 7 U
665 mm
Width 19 in
Case only without rack ears 449 mm
Depth 344 mm Excludes connectors/cables
Weight (†) 17 21 kg Depending on I/O fitted
Heat Dissipation 5 Mic cards 500 W Maximum
1 Mic, 2 analogue, 1 digital card 350 W Typical
Voltage Range 100 240 V ±10%, AC only
Current Maximum over voltage range 5.6 2.3 A
Power Factor 0.95 Approximately
Fusing Thermal current trip. No fuses
Noise Front 45 55 NR Variable speed fans
Rear 45 60 NR
Connectors Power in 1 and 2 IEC male
Network RJ45 100 baseT (unused)
Sync out BNC 75Ω (Wordclock)
Madi 1–4 Duplex LC fibre multimode
GPI Input 25-way D-type male
GPI Output 25-way D-type female
RIO units must be supported on rack shelves. Do not rely on the rack ears alone.
