Connector Pinouts
C100 HDS Installation Manual Section 4 – Appendices | Page 4-9
##
" "##"
"##.:2*5 *7-
Location: Console Additional Connector Panel
Connector Type: 9-way D-type Male
Pin Description Notes
1 Chassis
2 TX–
3 RX+
4 0V
5 nc No connection
6 0V
7 TX+
8 RX–
9 Chassis
"##.:2*5
Location: Blackrock Rear Panel
Connector Type: 9-way D-type Male
Pin Description Notes
1 n/c ‘Controller’ Pinout …
2 RX-
3 TX+
4 n/c
5 0V
6 n/c
7 RX+
8 TX-
9 n/c
