Fibre optic cabling will be required between the Blackrock processor(s) and each outboard I/O Unit – RIO, Alpha-link
LIVE-R, SDI-MADI and MORSE units all use duplex fibre for audio interfacing. Redundant systems will require two
individual fibre links to each outboard unit; see the examples on the following page.
The Alpha-Link 8-RMP microphone amplifiers do not require audio fibre connection to Blackrock. They connect to a local Alpha-
Link LIVE-R unit using analogue and network cabling.
It is a sensible practice to install spare cable runs to allow for system expansion or to replace any leads that may subsequently
become damaged.
The table below lists the cable and connector requirements.

 !
* MORSE units are fitted with multimode adapters as standard. Singlemode interfaces are available to special order only and will
have extended lead-times.
" #$"#
The default interface fibre interface adaptors fitted are suitable for multimode fibre connections. RIO stageboxes and
MORSE units may optionally be ordered with singlemode versions for any of the fibre links. (The corresponding port on
the Blackrock processor must also be changed to singlemode.) Alpha-Link LIVE is only available with multimode interfaces.
All SSL fibre interfaces use flat (PC) termination not angled (APC).
Singlemode and multimode interfaces and connectors are almost identical in appearance, however, they are operationally
incompatible – the two different standards cannot be mixed for any individual link.
The table below lists the fibre interface standards available and the maximum cable lengths permissable.
4:7)+ +89/3'9/43 '9'!>5+ 433+)9478 9'3*'7*
Blackrock RIO MADI or Blacklight LC – LC Multimode or Singlemode
Blackrock Alpha-Link LIVE-R MADI LC – SC Multimode
Blackrock MORSE Router MADI LC – SC Multimode or Singlemode*
Blackrock MORSE Stagebox MADI LC – SC Multimode or Singlemode*
Blackrock SDI–MADI I/F MADI LC – ST Multimode
MORSE Router MORSE Stagebox MADI SC – SC Multimode or Singlemode*
>89+242543+398
 389'11'9/43'3:'1 +)9/437+5'7'9/43? '-+
'9'!>5+ /(7+!>5+ 5+)/,/)'9/43 '=/2:2+3-9. 49+
MADI Multimode 50/125um 550m Default fitment
“ Multimode 62.5/125um <300m No longer available
“ Singlemode 9/125um 2,000m Option
Blacklight Multimode 50/125um 300m Default fitment
“ Multimode 62.5/125um 150m No longer available
“ Singlemode 9/125um 2,000m Option

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
