Solid State Logic C100 HDS User Manual

$=<
Location: Console Connector Panel
Connector Type: XLR 3-pin male
Pin Description Notes:
1 Chassis (screen)
2 + signal
3 – signal
$" %$#
##
C100 HDS Installation Manual Section 4 – Appendices | Page 4-7
Connector Pinouts
.<.:79=<; @ 7*580=.
Location: Console Connector Panel
Connector Type: 25-way D-type male
Pin Description VU Meters Only With RTW TM7
1 Circuit 1 input + Left VU meter Input 1
14 Circuit 1 input - And Left VU meter
2 -
15 Circuit 2 input + - Input 2
3 Circuit 2 input -
16 -
4 Circuit 3 input + Right VU meter Input 3
17 Circuit 3 input - And Right VU meter
5 -
18 Circuit 4 input + - Input 4
6 Circuit 4 input -
19 -
7 Circuit 5 input + - Input 5
20 Circuit 5 input -
8 -
21 Circuit 6 input + - Input 6
9 Circuit 6 input -
22 -
10 Circuit 7 input + - Input 7
23 Circuit 7 input -
11 -
24 Circuit 8 input + - Input 8
12 Circuit 8 input -
25 -
13 -

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
