Solid State Logic C100 HDS User Manual

Contents
C100 HDS Installation Manual Section 4 – Appendices | Page 4-1
#$@  #
#$ $$#
#9.,2/2,*<287; 
C100 HDS Console 4-2
RIO 4-3
Blackrock Processor 4-3
Alpha-Link 8-RMP 4-4
Alpha-Link Live 4-4
Console Footprint Drawing – 32 Channels 4-5
877.,<8:.<*25; 
877.,<8: 278=<; 
C100 HDS Console 4-7
TB Out 4-7
RS422 Serial 4-9
Blackrock Processor 4-9
RIO – Analogue and Digital I/O 4-10
Alpha-Link Live 4-11
Alpha-Link 8-RMP 4-12
GP IO 4-13
=-287<.:/*,270 
7>2:876.7<*5#9.,2/2,*<287 
#=998:<.-#?7,"*<.; 
# 
 (

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
