Solid State Logic C100 HDS User Manual

#87;85.
Parameter Condition Value Unit Notes
Height To top of meter trim 1,006 mm
Height adjustment -0 +10 mm
Width 32 channel without side trim 1,431 mm
8 channel bay (add/subtract) 285 mm
Contoured side trims +72 mm
Add 36mm each side
Depth 926 mm Additional 18mm for heatsinks
Weight 32 channel console with two legs 123 kg Approximately
8 channel bay (add/subtract) 26 kg “
Additional Leg 6.5 kg “
Heat Dissipation 32 channels 400 W Approximately
8 channel bay (add/subtract) 80 W “
Voltage Range 100 – 240 V ±10%, AC only
Current 32ch max. over voltage range 3.2 – 1.3 A
48ch max. over voltage range 5.1 – 1.9 A
Power Factor 0.95 Approximately
Fusing No user-accessible fuses
Noise Fanless
Connectors Power in Main/Backup IEC 3-pin male 10A
Network TCP/IP RJ45 100 baseT
USB (touchscreen) USB A
Meter input Analogue 25-way D-type male
Meter input Digital 25-way D-type female
T/B audio output XLR 3-way male
# $#
Page 4-2 | Section 4 – Appendices C100 HDS Installation Manual
Specifications

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
