Solid State Logic C100 HDS User Manual

##
Page 4-8 | Section 4 – Appendices C100 HDS Installation Manual
Connector Pinouts
.<.:2*078;<2,;87<:85
Location: Connector panel
Connector Type: 9-way D-type female
Pin Notes: MSD600 Notes: RTW10830
1 Chassis Switch common
6 - Mode
2 Rx Data Select
7 - Memo
3 Tx Data Gain
8 - Reset
4 - Shift
9 - -
5 - -
.<.:79=<; @ 202<*5
Location: Console Connector Panel
Connector Type: 25-way D-type female
Pin Description MSD600M RTW TM7
1 Circuit 1 + - AES/EBU out 7/8
14 Circuit 1 -
2 -
15 Circuit 2 + - AES/EBU out 5/6
3 Circuit 2 -
16 -
4 Circuit 3 + - AES/EBU out 3/4
17 Circuit 3 -
5 -
18 Circuit 4 + - AES/EBU out 1/2
6 Circuit 4 -
19 -
7 Circuit 5 + AES/EBU in 7/8 AES/EBU in 7/8
20 Circuit 5 -
8 -
21 Circuit 6 + AES/EBU in 5/6 AES/EBU in 5/6
9 Circuit 6 -
22 -
10 Circuit 7 + AES/EBU in 3/4 AES/EBU in 3/4
23 Circuit 7 -
11 -
24 Circuit 8 + AES/EBU in 1/2 AES/EBU in 1/2
12 Circuit 8 -
25 -
13 -
* The Digital Input and Diagnostics connectors will only be fitted if an LCD meter has been specified.

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
