Solid State Logic C100 HDS User Manual

>89+242543+398
'-+ ? +)9/437+5'7'9/43  389'11'9/43'3:'1
WORD
CLOCK
OUT
REMOTE
RMP 1
POWER
WORD CLOCK
VIDEO IN
USBAES/EBU - CAES/EBU - BAES/EBU - AOUT 1 IN 1 OUT 2 IN 2
MADI
ANALOGUE 17 – 24ANALOGUE 9 – 16ANALOGUE 1 – 8
OUT 9 – 16
IN 9 – 16
OUT 17 – 24
IN 17 – 24
OUT 1 – 8
IN 1 – 8
RMP 2
RMP 3
ANALOG 1 – 8
ANALOG 17 – 24ANALOG 9 – 16
AES / EBU – A AES / EBU – B AES / EBU – C
OUT
IN
OUT
IN
OUT
IN
EXPANSION PORT
MADI OUT MADI IN IN WORD CLOCK OUT
REMOTE
RMP - 1
RMP - 2
RMP - 3
POWER
VIDEO IN
  &"&
300mm
Rear Panel Connectors – Alpha Link Live-R
Rear Panel Connectors – Alpha Link Live
2U

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
