Tally
Related Topic
Resetting Unit Settings
Connecting the Unit to a Network Device Via Wired Connection
Accessing the Web App from a Web Browser
Outputting an Optical Fiber Signal
Connector Block
Resetting the Pan/Tilt
[P/T Range Limit]
Restoring Memory Cards
Connecting a Tally Signal
TP1001804717
5-065-326-11(1) Copyright 2024 Sony Corporation
Symptom Cause Solution
Cannot synchronize to
external source.
An external sync signal suitable for the
configured video signal format is not
being input.
Input an external sync signal suitable for the
configured video signal format.
Unit is double-terminated.
The unit has a built-in 75 Ω terminator. Connect
directly to a signal source (one-to-one) or use a
distributor (splitter).
Symptom Cause Solution
Tally lamp does
not light up.
The tally lamp brightness is set to Off.
Set the appropriate brightness using [Technical] –
[Tally] – [Tally Lamp Brightness] in the web menu.
The recording/tally lamp is configured as a
recording lamp or PTZ AFR indicator.
Configure the recording/tally lamp to function as a
tally lamp as described in “Connecting a Tally
Signal.”
RM-IP500 is connected and VISCA over IP is
disabled.
Set SETUP switch 4 to the ON position on the
connector block of the unit.
The OPTION connector connection is incorrect
or the target pin is not short-circuited to GND.
Short-circuit pin 7 or pin 8 of the OPTION connector
to GND as described in “Connecting a Tally Signal.”
