Pin No. Pin Name I/O Description
N1 VCCL_GXB_N1 - Power supply terminal (+1.2V)
N2 NC_N2 O Not used
N3 MSEL1 I Fixed at “L”
N4
IO/DIFFIO_B1P/
CRC_ERROR
O Not used
N5
IO/DIFFIO_B1N/
NCEO
O Not used
N6
IO/DIFFIO_B3N/
DQ0B
O Not used
N7 CLK15/DIFFCLK_6N I Not used
N8
IO/DIFFIO_B12P/
DQ0B
O Not used
N9
IO/DIFFIO_B12N/
DQ0B
O Not used
N10
IO/DIFFIO_B21P/
DQ0B
O Not used
N11
IO/DIFFIO_B21N/
DQ0B
O Not used
N12 IO/RDN2/DM0B O Not used
N13 IO/RUP3 O Bit clock signal output to the D/A converter
