Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
121
R526 1-218-929-11 METAL CHIP 10 5% 1/16W
R527 1-218-929-11 METAL CHIP 10 5% 1/16W
R528 1-218-929-11 METAL CHIP 10 5% 1/16W
R531 1-218-929-11 METAL CHIP 10 5% 1/16W
R532 1-218-929-11 METAL CHIP 10 5% 1/16W
R534 1-218-929-11 METAL CHIP 10 5% 1/16W
R549 1-218-941-81 METAL CHIP 100 5% 1/16W
R550 1-218-929-11 METAL CHIP 10 5% 1/16W
R551 1-218-941-81 METAL CHIP 100 5% 1/16W
R552 1-218-929-11 METAL CHIP 10 5% 1/16W
R553 1-218-929-11 METAL CHIP 10 5% 1/16W
R554 1-218-929-11 METAL CHIP 10 5% 1/16W
R555 1-218-929-11 METAL CHIP 10 5% 1/16W
R556 1-218-929-11 METAL CHIP 10 5% 1/16W
R557 1-218-929-11 METAL CHIP 10 5% 1/16W
R558 1-218-929-11 METAL CHIP 10 5% 1/16W
R559 1-218-929-11 METAL CHIP 10 5% 1/16W
R560 1-218-929-11 METAL CHIP 10 5% 1/16W
R561 1-218-929-11 METAL CHIP 10 5% 1/16W
R562 1-218-929-11 METAL CHIP 10 5% 1/16W
R570 1-218-965-11 METAL CHIP 10K 5% 1/16W
R575 1-218-990-81 SHORT CHIP 0
R576 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R577 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R578 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R579 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R580 1-218-965-11 METAL CHIP 10K 5% 1/16W
R581 1-218-965-11 METAL CHIP 10K 5% 1/16W
R582 1-218-965-11 METAL CHIP 10K 5% 1/16W
R701 1-216-864-11 SHORT CHIP 0
R702 1-216-864-11 SHORT CHIP 0
R703 1-218-929-11 METAL CHIP 10 5% 1/16W
R704 1-218-929-11 METAL CHIP 10 5% 1/16W
R705 1-218-929-11 METAL CHIP 10 5% 1/16W
R706 1-218-929-11 METAL CHIP 10 5% 1/16W
R707 1-218-929-11 METAL CHIP 10 5% 1/16W
R708 1-218-929-11 METAL CHIP 10 5% 1/16W
R709 1-218-933-11 METAL CHIP 22 5% 1/16W
R710 1-218-989-11 METAL CHIP 1M 5% 1/16W
R712 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R713 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R714 1-218-965-11 METAL CHIP 10K 5% 1/16W
R716 1-218-965-11 METAL CHIP 10K 5% 1/16W
R718 1-218-965-11 METAL CHIP 10K 5% 1/16W
R719 1-218-933-11 METAL CHIP 22 5% 1/16W
R720 1-218-941-81 METAL CHIP 100 5% 1/16W
R721 1-218-933-11 METAL CHIP 22 5% 1/16W
R722 1-218-933-11 METAL CHIP 22 5% 1/16W
R723 1-218-933-11 METAL CHIP 22 5% 1/16W
R724 1-218-933-11 METAL CHIP 22 5% 1/16W
R725 1-218-933-11 METAL CHIP 22 5% 1/16W
< VIBRATOR >
X201 1-814-147-11 QUARTZ CRYSTAL OSCILLATOR (50 MHz)
X701 1-795-374-21 VIBRATOR, CERAMIC (6 MHz)
*************************************************************
HP BOARD
*********
< CAPACITOR >
C2001 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2002 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
C2003 1-118-290-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN2001 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D2001 6-503-704-01 DIODE CUS521, H3SONYF
D2002 6-503-704-01 DIODE CUS521, H3SONYF
< LUG TERMINAL >
* ET2001 1-780-408-11 TERMINAL, LUG
< JACK >
J2001 1-822-967-12 JACK (PHONES)
< JUMPER RESISTOR >
R2001 1-216-864-11 SHORT CHIP 0
*************************************************************
A-1945-086-A KEY JOG BOARD, COMPLETE
***********************
< CAPACITOR >
C1008 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5050 1-118-385-11 CERAMIC CHIP 0.001uF 10% 50V
C5052 1-118-385-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN1001 1-573-290-21 PIN, CONNECTOR (1.5 mm) (SMD) 4P
CN5009 1-820-116-51 CONNECTOR, FFC/FPC 17P
CN5310 1-573-768-21 PIN, CONNECTOR (1.5 mm) (SMD) 5P
< LED >
D5002 6-502-413-01 LED SELT5E23C-S TP15 (DSEE)
< ROTARY ENCODER >
EN5004 1-418-725-41 ENCODER, ROTARY (12 TYPE) (VOLUME)
< IC >
IC1002 6-600-768-01 IC PNA4823M03S0 (
)
< TRANSISTOR >
Q5002 6-553-268-01 TRANSISTOR PDTC114ET
< RESISTOR >
R1018 1-216-809-11 METAL CHIP 100 5% 1/10W
R5014 1-216-818-11 METAL CHIP 560 5% 1/10W
R5117 1-216-809-11 METAL CHIP 100 5% 1/10W
R5118 1-216-809-11 METAL CHIP 100 5% 1/10W
R5572 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5573 1-216-797-11 METAL CHIP 10 5% 1/10W
FPGA DSP HP KEY JOG
